DBOH-3Z6SL-JH
HYBRIFLEX® Distribution Box, 3 Pairs DC, 12 Pairs Optical Fiber, for Tower, Pole or Wall Mounting, IP65

Rev : B | Rev date : 15 Nov 2025

RFS’ HYBRIFLEX Remote Radio Head (RRH) hybrid feeder cabling solution combines optical fiber and DC power for RRHs in a single lightweight aluminum corrugated cable, making it the world’s most innovative solution for RRH deployments. It was developed to reduce installation complexity and costs at Cellular sites.

The HYBRIFLEX Distribution Box is part of the cabling solution for Remote Radio Units. it may be mounted on a tower, rooftop or other suitible location near the RRUs and acts as an interface between the riser cable and the jumper cables.



Feature / Benefits

  • Configured for 1 hybrid riser in, 3 DC power jumpers and 3 fiber jumpers out
  • IP65 rated enclosure, allowing for indoor or outdoor installation on a roof or tower top
  • M12 pressure equalizing breather valve
  • Ground column
  • Mounting hardware included
  • RoHS Compliant
dboh-3z6sl-jh thumbnail image.png
Mechanical Specifications
Material UV resistant ABS and Polycarbonate
Dimensions (LxWxD) 345 x 314 x 150 (13.57 x 12.38 x 5.91)
Mounting Pole or Wall
Type of F/O Patch Panel LC-4A Adapter
Type of DC Terminal Screw terminal
Cables Supported
Number of Riser Cables supported 1
Diameter of Riser Cable 7/8 or 1-1/4
Supported F/O Connections 12 pairs DLC
Supported DC Connections 3 pairs
Number of Cables supported 6
Diameter of Jumper Cable 21.5mm (0.85in)
Electrical Specifications
Protection Class IP65
