Lifetime Connectivity

43M-LCF158-E01
4.3-10 Male Straight Connector for 1 5/8" Coaxial Cable, OMNI FIT™ Premium, O-Ring and compression sealing

Rev : C | Rev date : 15 Nov 2025
OMNI FIT™ high performance connectors are designed for use with both CELLFLEX® (copper) and CELLFLEX® Lite (aluminium) cables. They are designed specifically to provide the highest quality connector-cable interface while simplifying and speeding up connector attachment. All RFS connectors are fully tested for mechanical and electrical compliance to industry specifications.
The 4.3-10 connector is an innovative, space-saving RF connection meeting all requirements even under the most severe environmental conditions and not relying on coupling nut torque. Sealing against outer conductor and jacket by means of the o-ring and 360° compression fit. Multifunctional, self-lubricating HighTech polymer assembly locks on cable corrugation, avoids electrochemical potential differences and compression-fits to the jacket

Feature / Benefits

  • Ultra high PIM performance i.e. reduced interference leading to high customer satisfaction
  • Two-piece design i.e. visual inspection of interlocking leads to improved installation security
  • OMNI FIT™ concept i.e. streamlined order management and reduced stock level
  • Watertight sealing in mated and unmated condition, i.e. reduced efforts during installation and improved security during operation
  • Tri metal alloy plating i.e. extreme resistance against corrosion even under hardest climatic and environmental circumstances
  • Multi-thread (Tristart) design i.e. simplified and accelerated tightening process
  • RoHS (EU) and CRoHS (China) compliant i.e. can be used on a global basis
General Specifications
Cable Size 1 5/8
Cable Type Foam Dielectric, Radiating
Model Series LCF158-50A-Series LCF158-50L-Series
Connector Interface 4.3-10
Connector Type

OMNI FIT™ PREMIUM Straight
Sealing Method

O-ring
Testing and Environmental
Waterproof Level IP68
Mechanical Specifications
Plating Outer/Inner Trimetal/Silver
Length 94.6mm (3.724in)
Outer Diameter 62.8mm (2.472in)
Inner Contact Attachment Spring Finger
Outer Contact Attachment Spring Claw
Electrical Specifications
Nominal Impedance 50 ohms
3rd Order IM Product @ 2x20 Watts

-163, typical -167dBc
Maximum Frequency 2.75 GHz
Frequency Range VSWR value Return Loss value
0 < f ≤ 1.0 GHz 1.02 40.1
1.0 < f ≤ 2.2 GHz 1.03 36.6
2.2 < f ≤ 2.75 GHz 1.06 30.7
